INSTALLATION

Check the appliance is electrically safe and gas sound when you have nished.

ArtNo.010-0004 Moving the cooker

Lowering the Two Rear Rollers

To adjust the height of the rear of the cooker, rst t a 13 mm

spanner or socket wrench onto the hexagonal adjusting

nut (Fig. 9.5). Rotate the nut – clockwise to raise – counter-

clockwise to lower.

Make 10 complete (360°) turns clockwise.

Make sure you lower BOTH REAR ROLLERS.

Completing the Move

Unfold the rear edge of the cardboard base tray. Open the

oven doors so that you can get a good grip on the bottom of

the fascia panel as you move the oven (Fig. 9.6).

Carefully push the cooker backwards o the base tray.

Remove the base tray.

Position the cooker close to its nal position, leaving just

enough space to get behind it Fig. 9.7).

n

DO NOT use the door handles or control knobs to

manoeuvre the cooker.

Fitting the Stability Bracket or Chain

Unless otherwise stated, a cooker using a exible gas

connector must be secured with a suitable stability device.

Suitable stability devices are shown in Fig. 9.8 and Fig. 9.9.

If you are using a stability chain (Fig. 9.8) then the chain

should be kept as short as is practicable and xed rmly to

the rear of the cooker.

If you are using a stability bracket; rst attach the bracket

location device to the rear of the cooker (Fig. 9.9). Then

adjust the bracket to engage through the slot of the device

(Fig. 9.10 and Fig. 9.11).

Stability chain

Alternative positions

for stability location

bracket

Fig. 9.5

Fig. 9.6

Fig. 9.7

Fig. 9.8

Fig. 9.9
