INSTALLATION

Check the appliance is electrically safe and gas sound when you have nished.

Location of Cooker

The cooker may be installed in a kitchen/kitchen diner but

NOT in a room containing a bath or shower.

This appliance is designed for domestic cooking only. Use

for any other purpose could invalidate any warranty or

liability claim.

Note: An appliance for use on LPG must not be installed

in a room or internal space below ground level, e.g. in a

basement.

Conversion

This appliance is supplied set for G20 20 mbar Cat II

2H3+

A conversion kit for another gas is available for the cooker.

If the appliance is to be converted to another gas we

recommend that this is carried out before installation.

n

We recommend an overpressure shut-o device or

pressure relief valve be used in any LPG installation

to prevent exposure of downstream ttings /

appliances to excessive pressure (over 75mbar) in

event of regulator failure.

After converting the appliance, please attach the Gas

Conversion sticker over the appropriate area of the data

badge – this will identify the gas type for which the appliance

is now set.

You will need the following equipment to complete the

cooker installation satisfactorily:

• Stability bracket: If the cooker is to be supplied with gas

through a flexible hose, a stability bracket or chain must

be fitted. These are not supplied with the cooker but

are available at most builders’ merchants.

• Gas pressure tester/manometer.

• Flexible gas hose: Must be in accordance with the

relevant standards.

• Multimeter: For electrical checks.

You will also need the following tools:

1. Electric drill

2. Masonry drill bit (only required if tting the cooker on a

stone or concrete oor)

3. Wall plugs (only required if tting the cooker on a stone

or concrete oor)

4. Steel tape measure

5. Cross head screwdriver

6. Flat head screwdriver

7. Spirit level

8. Pencil

9. Adjustable spanner

10. Screws for tting stability bracket

11. 13 mm spanner or socket wrench

Checking the parts:

3 pan supports Wok cradle (Supplied)

ArtNo.110-0002 110 pan supports

ArtNo.000-0009 Wok ring, cast

Teppanyaki (Supplied) Griddle (Optional)

ArtNo.311-0043 - Griddle 09

Grill pan and trivet 1x set of Telescopic runners

2 Flat shelves Tall oven shelves & shelf supports

ArtNo.000-0010 Tall oven shelves

Plinth Stability location bracket

ArtNo.350-0009 - 90

Classic DL plinth
