INSTALLATION

Check the appliance is electrically safe and gas sound when you have nished.

Stability chain

Fig. 8.7

Fitting the stability bracket or

chain

Unless otherwise stated, a cooker using a exible gas

connector must be secured with a suitable stability device.

Suitable stability devices are shown in Fig. 8.7 and Fig. 8.8.

If you are using a stability chain (Fig. 8.7) then the chain

should be kept as short as is practicable and xed rmly to

the rear of the cooker.

If you are using a stability bracket (Fig. 8.8), rst attach the

bracket location device to the rear of the cooker (Fig. 8.8).

Then adjust the bracket to engage through the slot of the

device (Fig. 8.9 and Fig. 8.10).

Repositioning the cooker following

connection

If you need to move the cooker once it has been connected

then you need to unplug it and, having gripped under the

fascia panel and lifted the front of the cooker slightly

(Fig. 8.6), you need to check behind the cooker to make sure

that the gas hose is not caught.

As you progress, make sure that both the electricity cable and

gas hose always have sucient slack to allow the cooker to

move.

With a stability chain tted, release it as you ease the cooker

out. DO NOT forget to ret it when you replace the cooker.

When you replace the cooker, again check behind to make

sure that the electricity cable and gas hose are not caught or

trapped.

ArtNo.070-0014 - Stability bracket - Wall fitting

Cooker

Stability

bracket

Floor

Stability

location

bracket

Wall

Typical wall mounting

ArtNo.070-0014 - Stability bracket - Wall fitting

Cooker

Stability bracket

Floor

Stability

location

bracket

Typical oor mounting

Alternative positions

for stability location

bracket

Fig. 8.8

Fig. 8.9

Fig. 8.10
