Architectural Specications
e microphone preamplier shall be a single channel stand-alone unit with
a removable IEC power cord. e unit shall accept voltages from 100 to 240
VAC. e input and output shall be tted with XLR connectors. A polarity
inverting switch shall be included. Phantom power of no less than 48 volts
shall be provided in compliance with IEC 60268-15 and be controlled by a
slide switch with an LED indicator. A gain control shall be provided with 18-
66 dB adjustment range. Power, system signal and overload indicators shall
be provided. High current cross-coupled active output line driver shall be
standard, as well as input RFI lter protection.
e unit shall be a Rane MS1S Microphone Stage.
Block Diagram
SIGNAL / OVERLOAD
MIC
INPUT
PHANTOM
POWER
+48V
12-60 dB
GAIN
LEVEL
LINE
FILTER
RFI
OUT
INVERT
+6 dB
1
3
2
1
3
2
