Je bekijkt pagina 26 van 32
RW Manual-26
393-399 Mic 40 Parameters Same as Mic 1 Parameters
400-406 Mic 41 Parameters Same as Mic 1 Parameters
407-413 Mic 42 Parameters Same as Mic 1 Parameters
414-420 Mic 43 Parameters Same as Mic 1 Parameters
421-427 Mic 44 Parameters Same as Mic 1 Parameters
428-434 Mic 45 Parameters Same as Mic 1 Parameters
435-441 Mic 46 Parameters Same as Mic 1 Parameters
442-448 Mic 47 Parameters Same as Mic 1 Parameters
449-455 Mic 48 Parameters Same as Mic 1 Parameters
dB Conversion Chart for Attenuators
Transmitted Integer Value dB Attenuation
ECB 62e Global Parameters
Type: Bytes: Description:
Unit name 16 ASCII string
Port names 48 ASCII string: 1
st
8 bytes=name of Port 1, 2
nd
8 bytes=name of Port 2,... , 6
th
8 bytes=name of Port 6
Mic names 384 ASCII string: 1
st
8 bytes=name of Mic 1, 2
nd
8 bytes=name of Mic 2,... , 48
th
8 bytes=name of Mic 48
Unit lock flag 1 1 if unit is locked (read-only)
Elapsed time 4 Time of use in seconds (read-only) (Note: This is unsigned long integer. If bit 31 is set, it means an
error occurred, e.g. someone removed the EEPROM while the unit was powered and the time was restarted from that point.
Reserved 4 Normally set to 0,0,0,0 (factory use only)
Note: All ASCII strings are NULL terminated when they are less than the allocated string length. Otherwise, omit the NULL.
Device address (ADDR):
Valid address range is 1 through 250 (0, 251, 252, 253, 254, and 255 are reserved)
Device-type code (DT):
$30 = ECB 6
Manufacturer’s identification code (ID):
$08 = Rane Corporation
Channel number codes (CHNUM):
Always set to $00 except when the following DCL commands are issued: Program channel from memory (a.k.a. Program
Device), Mute channel (a.k.a. Mute port), and Unmute channel (a.k.a. Unmute port).
0.5 dB Steps 1 dB Steps 2 dB Steps
Dec Hex dB Dec Hex dB Dec Hex dB Dec Hex dB Dec Hex dB
0 $00 0.0 16 $10 8.0 32 $20 16.0 48 $30 32.0 64 $40 48.0
1 $01 0.5 17 $11 8.5 33 $21 17.0 49 $31 33.0 65 $41 50.0
2 $02 1.0 18 $12 9.0 34 $22 18.0 50 $32 34.0 66 $42 52.0
3 $03 1.5 19 $13 9.5 35 $23 19.0 51 $33 35.0 67 $43 54.0
4 $04 2.0 20 $14 10.0 36 $24 20.0 52 $34 36.0 68 $44 56.0
5 $05 2.5 21 $15 10.5 37 $25 21.0 53 $35 37.0 69 $45 58.0
6 $06 3.0 22 $16 11.0 38 $26 22.0 54 $36 38.0 70 $46 60.0
7 $07 3.5 23 $17 11.5 39 $27 23.0 55 $37 39.0 71 $47 62.0
8 $08 4.0 24 $18 12.0 40 $28 24.0 56 $38 40.0 72 $48 64.0
9 $09 4.5 25 $19 12.5 41 $29 25.0 57 $39 41.0 73 $49 66.0
10 $0A 5.0 26 $1A 13.0 42 $2A 26.0 58 $3A 42.0 74 $4A 68.0
11 $0B 5.5 27 $1B 13.5 43 $2B 27.0 59 $3B 43.0 75 $4B 70.0
12 $0C 6.0 28 $1C 14.0 44 $2C 28.0 60 $3C 44.0 76 $4C 72.0
13 $0D 6.5 29 $1D 14.5 45 $2D 29.0 61 $3D 45.0 77 $4D 74.0
14 $0E 7.0 30 $1E 15.0 46 $2E 30.0 62 $3E 46.0 78 $4E 76.0
15 $0F 7.5 31 $1F 15.5 47 $2F 31.0 63 $3F 47.0 79 $4F 100
100 $64 100
