3 OM-SERVING LINES
WATERBATH HOT FOOD WELLS
MODEL LENGTH DEPTH HEIGHT
NO. OF
WELLS
NO. OF
ELEMENTS
120V 208V
240V
SHIP
WT.
500W 1100W 865W 1100W 1100W
AMPS* NEMA AMPS* NEMA AMPS*
NEMA
AMPS*
NEMA AMPS* NEMA
Closed Base - Steel
RAN HTD-2 30" 27"
35.5"
2 2 8.33 5-15P 18.33 5-30P 8.32 6-15P 10.58 6-15P 9.17 6-15P 175
RAN HTD-3 48" 27"
35.5"
3 3 12.50 5-20P 27.5 5-50P 12.48 6-20P 15.87 6-20P 13.75 6-20P 215
RAN HTD-4 60" 27"
35.5"
4 4 16.67 5-30P 36.67 5-50P 16.63 6-30P 21.15 6-30P 18.33 6-30P 260
RAN HTD-5 72" 27"
35.5"
5 5 20.83 5-30P N/A N/A 20.79 6-30P 26.44 6-50P 22.92 6-30P 325
RAN HTD-6 86" 27"
35.5"
6 6 25 5-50P N/A N/A 24.95 6-50P 31.73 6-50P 27.5 6-50P 390
Open Base - Steel
RAN HTD-2S 30" 27"
35.5"
2 2 8.33 5-15P 18.33 5-30P 8.32 6-15P 10.58 6-15P 9.17 6-15P 175
RAN HTD-3S 48" 27"
35.5"
3 3 12.50 5-20P 27.5 5-50P 12.48 6-20P 15.87 6-20P 13.75 6-20P 215
RAN HTD-4S 60" 27"
35.5"
4 4 16.67 5-30P 36.67 5-50P 16.63 6-30P 21.15 6-30P 18.33 6-30P 260
RAN HTD-5S 72" 27"
35.5"
5 5 20.83 5-30P N/A N/A 20.79 6-30P 26.44 6-50P 22.92 6-30P 325
RAN HTD-6S 86" 27"
35.5"
6 6 25 5-50P N/A N/A 24.95 6-50P 31.73 6-50P 27.5 6-50P 390
Heated Base - Steel
RAN HTD-3B 48" 27"
35.5"
3 3 20.83 5-30P 35.83 5-50P N/A N/A 20.03 6-30P 17.92 6-30P 230
RAN HTD-4B 60" 27"
35.5"
4 4 25 5-50P N/A N/A N/A N/A 25.32 6-50P 22.5 6-30P 275
RAN HTD-5B 72" 27"
35.5"
5 5 N/A N/A N/A N/A N/A N/A 30.61 6-50P 27.09 6-50P 350
RAN HTD-6B 86" 27"
35.5"
6 6 N/A N/A N/A N/A N/A N/A 35.9 6-50P 31.67 6-50P 415
Closed Base - Fiberglass
RANFG HTD-2 30" 30"
35.5"
2 2 8.33 5-15P 18.33 5-30P 8.32 6-15P 10.58 6-15P 9.17 6-15P 175
RANFG HTD-3 48" 30"
35.5"
3 3 12.50 5-20P 27.5 5-50P 12.48 6-20P 15.87 6-20P 13.75 6-20P 215
RANFG HTD-4 60” 30"
35.5"
4 4 16.67 5-30P 36.67 5-50P 16.63 6-30P 21.15 6-30P 18.33 6-30P 260
RANFG HTD-5 72" 30"
35.5"
5 5 20.83 5-30P N/A N/A 20.79 6-30P 26.44 6-50P 22.92 6-30P 325
RANFG HTD-6 86" 30"
35.5"
6 6 25 5-50P N/A N/A 24.95 6-50P 31.73 6-50P 27.5 6-50P 390
Open Base - Fiberglass
RANFG HTD-3S 48" 30"
35.5"
3 3 12.50 5-20P 27.5 5-50P 12.48 6-20P 15.87 6-20P 13.75 6-20P 215
RANFG HTD-4S 60” 30"
35.5"
4 4 16.67 5-30P 36.67 5-50P 16.63 6-30P 21.15 6-30P 18.33 6-30P 260
RANFG HTD-5S 72" 30"
35.5"
5 5 20.83 5-30P N/A N/A 20.79 6-30P 26.44 6-50P 22.92 6-30P 325
RANFG HTD-6S 86" 30"
35.5"
6 6 25 5-50P N/A N/A 24.95 6-50P 31.73 6-50P 27.5 6-50P 390
Heated Base - Fiberglass
RANFG HTD-3B 48" 30"
35.5"
3 3 20.83 5-30P 35.83 5-50P N/A N/A 20.03 6-30P 17.92 6-30P 230
RANFG HTD-4B 60" 30"
35.5"
4 4 25 5-50P N/A N/A N/A N/A 25.32 6-50P 22.5 6-30P 275
RANFG HTD-5B 72” 30"
35.5"
5 5 N/A N/A N/A N/A N/A N/A 30.61 6-50P 27.09 6-50P 350
RANFG HTD-6B 86" 30"
35.5"
6 6 N/A N/A N/A N/A N/A N/A 35.9 6-50P 31.67 6-50P 415
*Note: Amperage for base unit only. Any accessory heat lamp or display illumination loads must be added to the total amperage.
