4 OM-20000 SERIES LOW PROFILE EQUIPMENT TABLES
MAINTENANCE
WARNING: DO NOT USE SHARP UTENSILS AND/OR OBJECTS.
WARNING: DO NOT USE STEEL PADS, WIRE BRUSHES, SCRAPERS, OR CHLORIDE
CLEANERS TO CLEAN YOUR STAINLESS STEEL.
CAUTION: DO NOT USE ABRASIVE CLEANING SOLVENTS, AND NEVER USE
HYDROCHLORIC ACID (MURIATIC ACID) ON STAINLESS STEEL.
WARNING: DO NOT PRESSURE WASH EQUIPMENT AS DAMAGE TO ELECTRICAL
COMPONENTS MAY RESULT.
Randell strongly suggests a preventive maintenance program which would include
the following monthly procedures:
If a failure of the equipment is a direct result of any of the Preventative Maintenance
guidelines being neglected, the repairs and parts replacements will not be covered
under warranty.
It is recommended that the customer contact the local Authorized Service Agent to
provide a quote to perform periodic Preventative Maintenance.
MONTHLY PM PROCEDURES
1. Cleaning of all condenser coils. Condenser coils are a critical component in
the life of the compressor and must remain clean to assure proper air ow and
heat transfer. Failure to maintain this heat transfer will affect unit performance
and eventually destroy the compressor. Clean the condenser coils with coil
cleaner and/or a vacuum, cleaner and brush. NOTE: Brush coil in direction of
ns, normally vertically as to not damage or restrict air from passing through
condenser.
2. Clean fan blade on the condensing unit.
3. Clean and disinfect drains with a solution of warm water and mild detergent
4. Clean and disinfect drain lines and evaporator pan with a solution of warm
water and mild detergent
5. Clean all gaskets on a weekly if not daily basis with a solution of warm water
and a mild detergent to extend gasket life.
6. Remove debris from drawer slides.
RECOMMENDED CLEANERS FOR YOUR STAINLESS STEEL INCLUDE THE
FOLLOWING:
JOB CLEANING AGENT COMMENTS
Routine cleaning
Soap, ammonia,
detergent Medallion
Apply with a sponge or
cloth
Fingerprints and smears
Arcal 20, Lac-O-Nu,
Ecoshine
Provides a barrier lm
Stubborn stains and
discoloration
Cameo, Talc, Zud,
First Impression
Rub in the direction of
the polish lines
Greasy and fatty acids, blood,
burnt-on foods
Easy-Off, Degrease It,
Oven Aid
Excellent removal on all
nishes
Grease and Oil
Any good commercial
detergent
Apply with a sponge or
cloth
Restoration/Preservation Benet, Super Sheen Good idea monthly
Reference: Nickel Development Institute, Diversey Lever, Savin, Ecolab, NAFEM
Proper maintenance of equipment is the ultimate necessity in preventing costly
repairs. By evaluating each unit on a regular schedule, you can often catch
and repair minor problems before they completely disable the unit and become
burdensome on your entire operation.
For more information on preventive maintenance, consult your local service
company or CFESA member. Most repair companies offer this service at very
reasonable rates to allow you the time you need to run your business along with
the peace of mind that all your equipment will last throughout its expected life.
These services often offer guarantees as well as the exibility in scheduling or
maintenance for your convenience. For a complete listing of current Randell ASA
please visit www.uniedbrands.net.
Randell believes strongly in the products it manufactures and backs those
products with one of the best warranties in the industry. We believe with the
proper maintenance and use, you will realize a protable return on your investment
and years of satised service.
REPLACEMENT PARTS
To order parts, contact your Authorized Service Agent. Supply the model
designation, serial number, part description, part number, quantity, and when
applicable, voltage and phase.
CONTACT US
If you have questions pertaining to the content in this manual, contact Randell
at 888-994-7636.
TROUBLESHOOTING
This unit is designed to operate smoothly and efciently if properly maintained.
However, the following is a list of checks to make in the event of a problem. Wir-
ing diagrams are found at the end of this manual. When in doubt, turn unit off
and call for service at 888-994-7636.
SYMPTOM POSSIBLE CAUSE PROCEDURE
Unit does not run
1. No power to unit
2. Power switch in OFF
position
3. Temperature control
turned off
4. Temperature control
faulty
5. Compressor overheated
6. Condenser fan faulty
7. Overload protector
faulty
8. Compressor relay faulty
9. Compressor faulty
1. Plug in unit
2. Switch power switch to
ON
3. Check temperature control
4. Test temperature control
5. Clean condenser coil
6. Service condenser fan
7. Test overload
8. Test relay
9. Call for service at 888-
994-7636
Unit short cycles
1. Condenser coil dirty
2. Condenser fan faulty
3. Compressor faulty
4. Overload repeatedly
tripping
1. Clean coil
2. Service fan and motor
3. Call for service at 888-
994-7636
4. Check outlet voltage
Unit runs constantly
1. Condenser coil dirty
2. Condenser fan faulty
3. Room ambient too high
4. Room humidity too high
5. Frost build up
6. Door gasket damaged
7. Poor door seal
1. Clean coil
2. Service condenser motor
3. Reduce room temperature
4. Set room lower
5. Defrost evaporator
6. Replace door gasket
7. Check door seal
Unit not cold enough
1. Temperature control set
too high
2. Temperature control
faulty
3. Condenser coil dirty
4. Refrigerant leaking or
contaminated
5. Room ambient too high
6. Room humidity too high
7. Door gasket damaged
8. Poor door seal
9. Evaporator fan faulty
10. Evaporator iced up
1. Adjust control to lower
setting
2. Test control
3. Clean coil
4. Call for service at 888-
994-7636
5. Reduce room temperature
6. Set room lower
7. Replace door gasket
8. Check door seal
9. Service evaporator fan
10. Defrost evaporator, Test
defrost timer, Test Therm-
O-Disc, Test defrost timer
Unit too cold
1. Temperature control set
too low
2. Temperature control
faulty
1. Adjust control to raise
setting
2. Test control
