Powerstrip™ Power Rack

True to the Music

Radial Engineering Ltd.

FEED SWITCH

As you delve further into the functionality of the 500 series, you will nd that the modular

format allows all kinds of connectivity options. With older 500 series racks, connections

between modules were done using an XLR cable whereby the output from one module would

plug into the input of another. The Cube simplies the process by introducing a FEED switch

on the rear panel. This connects the balanced output of one module to the adjacent module

to the immediate left when viewing the rear panel.

The FEED switch allows you to daisy chain a series of adjacent modules making it easy

to create a customized channel strip whereby a mic preamp feeds an EQ which in turn

could feed a compressor. Changing the order is simply a matter of relocating the modules or

patching using an XLR cable. The UP position turns the FEED connection on.

The 1/4" TRS connectors are also great for cross-patching between modules. Think of it like

a patchbay. Simply take the output from one, feed it into another and then jump back. This

opens many creative options and loads more fun.

STEREO LINK SWITCH

Card-slots one and two are equipped with a LINK switch. The LINK function allows modules

that are ‘stereo ready’ to be linked together. A typical example would be using two limiters on

a stereo track where you want the dynamics to be the same for both channels.
