True to the Music
®
Radial Engineering Ltd.
Decoder Mid/Side Matrix
2
14
15 16 17
21
18 19 20
REAR PANEL FEATURES
21. INPUT LEVEL SELECTOR: Allows user to select mic or line level
on each channel. Switches are recessed to prevent accidental
changes while recording
14. CABLE CLAMP: Used to secure the power supply cable in mobile
installations
15. POWER: 15VDC power connection for external power supply
16. RIGHT & LEFT OUTPUTS: Balanced +4dBu XLR stereo outputs
17. MIC 1 IN: Mic/line input for main ‘MID’ microphone or line source
18. INPUT-2a: Mic/line input for ‘SIDE’ microphone or line source
19. INPUT-2b: Mic/line input for optional third microphone or line source
20. NO SLIP PAD: A full pad covers the underside, keeps the Decoder
in one place and won’t scratch your mixing console
TOP PANEL FEATURES
