42
EN
6.2 Obstacle detection function
Function of the obstacle detection
when lowering the screen
The tubular motor stops and automatically shifts
briefly in the opposite direction (reverses) in the
event that the screen hits an obstacle while it is
being lowered.
Requirements for correct obstacle detection:
◆ The catch (7) must be mounted with the free-
wheel mechanism (see fig. 8, page 46), origi-
nal factory settings.
◆ The obstacle detection can be
activated/deactivated via the HomePilot®.
6.3 Jog mode using a button
The RolloTube S-line Zip DuoFern can be con-
trolled on site in jog mode using a button.
By briefly tapping the up or down button, the
screen will travel up or down completely until it
reaches the set end point. Tapping the button or
the opposite direction once more causes the mo-
tor to stop.
After pressing and holding the up or down button
(for more than approx. 1 second), the motor stops
when the button is released!
i
6.4 Operation using a switch
The RolloTube S-line Zip DuoFern can be con-
trolled on site using a switch.
By pressing the up or down direction on the
switch, the screen will lower or raise completely
until it reaches the set end point. By deactivating
the specified direction of travel, the motor can be
stopped at the desired position.
i
6.5 Jog mode using a 1-pole button
The RolloTube S-line Zip DuoFern can also be con-
trolled on site using a 1-pole button.
Activating the function
The function is deactivated in the factory settings;
once the button has been connected, the function
must first be activated on the tubular motor, see
page 53.
The function can be deactivated again as required.
Switching sequence on the button
Up / stop / down / stop etc.
i
i
Information about multi-part systems
i
When using a tubular motor with ob-
stacle detection in multi-part systems
(several screens powered by a wind-
ing shaft), the obstacle detection may
respond late or not at all.
