3.1 Intended use / operational conditions

Only use the tubular motors for opening and closing

standard ﬂat roller shutters and awnings.

The use of the wrong tubular motors or compo-

nents can lead to property damage.

◆ The motor cable must therefore be ﬁtted with a

suitable empty tube up to the respective junction

box under observation of local electrical regula-

tions, if installed outside.

◆ Only use the manufacturer's original parts and

accessories.

◆ Only use tubular motors which correspond to

the local conditions in terms of their power.

Incorrectly dimensioned tubular motors can lead

to damage:

> An insuﬃciently dimensioned tubular motor

can be damaged due to overloading.

> An excessively dimensioned tubular motor

can,

for example, cause damage to the roller shut-

ter or roller shutter box in self-learning mode.

◆ Consult a specialist retailer when selecting a

tubular motor and observe the corresponding

tractive force specifications on our website:

www.rademacher.de

Operating conditions

◆ A 230 V / 50 Hz power supply, together with a site-

provided isolating device (fuse) must be perma-

nently available for the electrical connection at the

installation location.

◆ The roller shutter must run up and down smoothly.

It should not jam.

Operating conditions for the self-learning

operation

◆ The roller shutter must be ﬁtted with stoppers or

an end-rail, see page 48.

◆ Otherwise, the end points must be set manually

in the conventional way, see page 54 et seq.

3.2 Improper use

Using the RolloTube M-line for purposes other than

previously mentioned is impermissible.

Never use the tubular motor in systems with in-

creased safety-relevant requirements or where

there is an increased risk of accidents.

◆ Applications of this kind require additional safety

equipment. Observe the respective statutory

regulations for the installation of such systems.

Never use the tubular motor in continuous opera-

tion. Doing so will cause serious damage.

Never use the tubular motor for shutters with

openings of ≥ 50 mm in diameter.

3.3 Required expert knowledge of the installer

The installation, electrical connection and main-

tenance must be carried out by a qualiﬁed person

with appropriate training or by a specialist roller

shutter ﬁrm in accordance with the instructions in

this manual.
