Specifications
13
balance
tone
bass
mm mc
phono tone backlight standbyaux 1 aux 2 aux 3 xlr
t i l t
Important Safety
Information
Controls and
Functions
Remote
Handset
System
Connection
WarrantySpecifications
Connections
System
Operations
Getting Started
Contents
General Description
Design Philosophy and Core Technology
Inputs
Outputs
Power Amplifier Section
Gain
Input Sensitivity (Vout=695mV)
Input Impedance
Total Harmonic Distortion (THD)
Frequency Response
Signal-to-Noise ratio (S/N)
Output Impedance
Headphone Amplifier
Total Harmonic Distortion (THD)
Output Impedance
Load Impedance
Pre Amplifier
Illuminated LCD screen
Dedicated High Performance Low Noise MM/MC Phono stage
Classic QUAD ‘Tilt’ adjustment
Classic QUAD /Tone Controls
Dedicated Current-Feedback Headphone Amplifier
3 x RCA , 1 x Balanced XLR , 1 x Phono (MM/MC switchable)
1 x RCA (AUX), 1 x XLR, 1 x RCA(Pre Out),
1 x Headphone, 2 x 12V Trigger Out
0dB (Line / XLR)
+46dB (Phono MM)
+63.5dB (Phono MC)
695mV (Line / XLR)
3.2mV (Phono MM)
460uV (Phono MC)
10k (Line / XLR)
47k/100pF (Phono MM)
100R/1.7nF (Phono MC)
<0.0005% (1kHz, Line/XLR)
<0.002% (1kHz, Phono MM / MC)
20Hz - 20kHz (+/-0.2dB)
> 108dB (A-weighted, Line/XLR)
> 82dB (A-weighted, Phono MM)
> 74dB (A-weighted, Phono MC)
120 ohms
< 0.01% (1kHz, 50mW )
2.35 ohms
20 - 600 ohms
Model
QUAD 33
General
Standby Power Consumption
Net weight
Gross weight
Dimensions (mm) (W x H x D)
Carton Size (mm) (W x H x D)
Finish
Power requirements (depending on region)
Standard accessories
<0.5W
4kg
4.96kg
258 x 94
x 165
330 x 192 x 257
Classic QUAD Grey
220 - 240V - 50 / 60Hz
100 - 120V - 50 / 60Hz
Power Cable,
Remote Control, 2
x AAA batteries,
User Manual
