5.1 – Device Specifications
Video Specifications
HDCP
V2.2
HDMI
V2.0
Supported
Resolutions
4096×2160p@23.98,24/25/29.97,30/50/59.
97,60Hz,
3840×2160p@23.98,24/25/29.97,30/50/59.
97,60Hz (UHD),
2048x1080p,1080p@23.98/24/25/29.97/30
/50/59.94/60Hz, 1080i@50/59.94/60Hz,
720p@50/59.94/60Hz, 576p,
576i, 480p, 480i
3D Support
Color Space
YUV, RGB
Chroma
Subsampling
4:4:4, 4:2:2, 4:2:0
Max Color Depth
48 bit
EDID
SW Configurable
Hot Plug Detect
SW Configurable
Bandwidth
18 Gbps (600 MHz)
Connectors
HDMI Type A
Dante Network
Physical Layer
Ethernet
Connector:
Single RJ-45
Cable Quality:
CAT-5e or better
Transmission Speed:
100 Mbps
Supported Sample
Rates
48kHz
Minimum Dante
Network Latency
1ms
Power Requirements
PoE
802.3af PoE PD compliant
Power Consumption
< 7.6W Max
Cable Quality:
CAT-5e or better
Physical Dimensions
Width
9.19”
Height
1.06”
Depth
4.0”
Weight
1.3lbs
Product Compliance
FCC CFR 47 Parts 15B Class A, EN55011
ICES-003
CE (EN55022 / EN55024)
RoHS
REACH
Analog Audio Inputs
Input Type
Balanced 3-pin line level
Input Sensitivity
–10dBV (consumer) or +4dBu (Pro)
software selectable
Input Impedance
10 kΩ
Maximum Input
Levels
+20 dBu (+/- 0.5 dB) @ +4dBu Input
Sensitivity
+10 dBV (+/- 0.5 dB) @
-10 dBV Input Sensitivity
THD+N
< 0.005 %
Dynamic Range
> 105 dB
Analog Audio Outputs
Output Type:
Balanced 3-pin line level
Output Impedance:
200 Ohms Balanced
Maximum output
level:
+20 dBu (+/- 0.5 dB)
THD+N:
< 0.005 %
Dynamic Range:
> 105 dB
S/PDIF Audio Inputs
Supported Formats
S/PDIF ( IEC-60598)
2 CH PCM, 24bit
Supported Sample
Rates
44.1 kHz, 48 kHz, 88.2kHz, 96 kHz, 192
kHz
THD+N:
< 0.005 %
S/PDIF Audio Output (Mirrors HDMI Input Audio)
Supported Formats
S/PDIF ( IEC-60598)
2 CH PCM, 24bit
Compressed Multi-channel in Pass
Through mode
Supported Sample
Rates
44.1 kHz, 48 kHz, 88.2kHz, 96 kHz, 192
kHz
THD+N:
< 0.005 %
HDMI Audio Inputs
Supported Formats
2 CH PCM, 24bit
Supported Sample
Rates
44.1 kHz, 48 kHz, 88.2kHz, 96 kHz, 192
kHz
THD+N:
< 0.005 %
HDMI Audio Output
Supported Formats
2 CH PCM, 24bit
Compressed Multi-channel in Pass
Through mode
Supported Sample
Rates
44.1 kHz, 48 kHz, 88.2kHz, 96 kHz, 192
kHz
THD+N:
< 0.005 %
