Je bekijkt pagina 13 van 13
Attero Tech by QSC Synapse D16Mio
User Manual
Ó QSC, LLC 2020 614-00051
Device Specifications
Dante Network
Physical Layer
Ethernet
Connector (s)
Dual RJ-45 / Dual SFP Slots
Cable Quality
CAT-5e or better (Copper) / Fiber
Transmission Speed
All interfaces 1 Gbps
Supported Sample Rates
44.1kHz /48kHz / 88.2 kHz / 96 kHz
Minimum Dante
Network Latency
250 us
Supported Modes
Redundant / Switched
AES67 Support
Dante™ – AES67 Mode
Power Specifications
AC Power
120V AC
Power Consumption
< 20W Max
Cable Quality
CAT-5e or better
Physical Dimensions
Width
19"
Height
1.75” (1 RU Form Factor)
Depth
12.5"
Weight
6 lbs.
Regulatory Compliance
Certifications
FCC CFR 47 Parts 15B Class A, EN55011
ICES-003
CE (EN55022 / EN55024)
RoHS
REACH
Environmental Operating Specifications
Operating Temperature
0 to 40° C
Analog Audio Inputs
Input Type
16 – Balanced 3-pin mic/line level (Terminal Block
option)
2 – TASCAM-pinout compatible DB25 balanced analog
(DB-25 option)
Input Impedance
2 kΩ minimum (Mic Mode)
10 kΩ (Line Mode)
Maximum Input Levels
-43 dBu (Max Mic Gain)
+24 dBu (Pad Active – Line Mode)
THD+N
≤ 0.005%, ≤ 0.015% (Max Gain)
Dynamic Range
≥ 105 dB (Pad on)
Frequency Response
20-20kHz, +/- 0.5dB
Analog Audio Outputs
Output Type
16 – Balanced 3-pin line level (Terminal Block option)
2 – TASCAM-pinout compatible DB25 balanced analog
(DB-25)
Output Impedance
200 Ω - Balanced
Maximum Output Levels
+24 dBu (+/- 0.5 dB)
THD+N
≤ 0.05%
Dynamic Range
≥ 110 dB
Frequency Response
20-20kHz, +/- 0.5dB
Headphone Output
Output Type
Stereo headphone on ¼” TRS
Maximum output level
25mW into 32 Ω
THD+N
< 0.01 % @ 25mW
