TD-000343-00-C

Introduction

Q-Sys™ is a platform of software and hardware products that provide the system designer and system operator with all the tools necessary to design,

conﬁ gure, and manage medium to large scale audio systems. In addition to the primary signal processing and system management components

that make up a Q-Sys audio system, the Q-Sys solution includes peripheral components that offer services such as remote management and paging.

This manual addresses the features and speciﬁ cations related to the hardware components of the Q-Sys TSC-3 series networked touchscreen

controller peripherals.

The Q-Sys TSC-3 series touchscreen controllers are sophisticated network devices that provide remote management services for a Q-Sys audio system.

Like all Q-Sys system components, functionality of the TSC-3 touchscreen controllers is deﬁ ned and conﬁ gured by the system designer using Q-Sys

Designer. Q-Sys Designer is Windows-based software used to design, and optionally manage, a Q-Sys system. Once a Q-Sys design ﬁ le has been

created, it is then deployed to a Q-Sys Core Processor over the Q-LAN network. The Q-Sys Core Processor is the centralized processing entity for the

Q-Sys system. The Q-Sys Core Processor pushes all necessary design and conﬁ guration information to each end node in the system, including TSC-3

touchscreen controllers.

The TSC-3 series touchscreen controllers connect to a Q-Sys system by joining the Q-LAN network. Once connected to the network, the Q-Sys Core

Processor can automatically discover the TSC-3 device, assimilate it into the Q-Sys system and push the appropriate conﬁ guration, as deﬁ ned in the

Q-Sys Designer design ﬁ le, to the controller. Once assimilated into the Q-Sys system, the TSC-3 can be operated using its front panel user interface

without further need of a computer, running Q-Sys Designer, in the system.

Q-LAN is QSC’s proprietary time-sensitive gigabit Ethernet network implementation built on standard protocols and off-the-shelf network hardware

and cabling. Q-LAN represents state of the art in real-time networking technology appropriate for live performance multimedia applications. In

addition to providing low-latency audio services, Q-LAN also provides conﬁ guration and management services to all Q-Sys products and peripherals

in the system.

TSC-3 Features

The TSC-3 series products are network enabled capacitive touchscreen control panels. The TSC-3 products are designed to connect to a Q-Sys system

via Q-LAN or to an auxiliary network to which the system Core Processor(s) is connected. The TSC-3 connects to the Q-LAN network to provide system

managers and/or end users with remote management capabilities of their Q-Sys system. Since the TSC-3 products do not provide low latency un-

compressed audio services, these products can join a Q-LAN network via standard 10/100 Mbps Ethernet connections.

The TSC-3 products include a 3.5", 4:3 (320 x 240) color graphics display with a 240 nit LCD. The control surface is a capacitive touch interface that is

reliable, bright, and easy to use.

The TSC-3 is powered by IEEE 802.3AF power over Ethernet (PoE) on a 10/100 Mbps connection.

TSC-3 products have a ﬂ exible mounting system that allows mounting to the surface of a wall or podium, mounting in a wall with a standard U.S.

2-gang electrical wall box (new construction and old construction), and mounting in a wall by itself.
