POWER
AUX IN
MASTER VOLUME
E-1500 BLUETOOTH
Bluetooth Mode: Use the MODE button to enable Bluetooth on the E-1500. Open the Bluetooth settings on
your mobile device and search for QFX E-1500. Select the option to pair both devices together. You can now
sit back and enjoy the music from your favorite app. You won't need reconnect the Bluetooth again when
switching through modes.
E-1500 FM RADIO:
FM Radio: Frequency-Modulated stations operate in a frequency band extending from 87.5 MHz to 108 MHz.
Use the MODE button to select the FM mode. In FM mode, press and hold the Play/Pause button to scan
available frequencies in the area. Extend the telescoping antenna to enhance reception.
6 - STEP SETUP GUIDE
Step Find the AC power cord to the
E-1500 located on the back panel of the unit.
Step Find a power outlet (AC 120V/60Hz)
and connect the AC cord to the socket to
supply the unit with power.
Step Move to the top panel and set the
POWER switch to the “ON” position. The
display screen should turn on. The E-1500
should now be ready to play music. If the
Display doesn’t turn on, try a different power
source.
Step On the back panel next to the RCA
inputs, there is a LED. LIGHT switch. Set the
switch to the “ON” position. Check the front
side for of the E-1500 for flashing party lights.
Step Insert a USB flash drive or SD card
into the corresponding port, found directly
under the display screen, to play your .mp3
content. The E-1500 will automatically read the
.mp3 files when inserted.
Step The MASTER VOLUME will increase
and decrease the entire volume evenly. Make
sure that the L and R Channel Knobs are turned
to max before gradually raising the MASTER
VOLUME.
1 Back Panel
3
Top Panel
Font Side
QUICK START GUIDE
