User Manual
PT-SCREEN-100
17
1/4 inch screw hole
There are four 1/4 inch screw holes on the up, bottom,
left and right side of housing.
These screw holes can be used with tripod stand.
• When used with optional Sun Shade (PT-SCREEN-SUS),
need to x with 1/4 inch screw hole on the upper side
of housing.
• When used optional U-Stand (PT-SCREEN-STD), need
to x with the left and right side housing.
V Mount Battery Plate
On the back of the display, there is a space reserved for
the V Mount Battery Plate.
4 pin Mini XLR Pin Assignment
Make sure the 4 pin mini XLR pin assignment before
use.
If pin assignment of mini XLR connector is
not connect, this could damage the whole
unit of PT-SCREEN-100.
