User Manual
PT-MA-HD44M
4
Introduction to PT-MA-HD44M
The PT-MA-HD44M is a HDMI 2.0 4x4 Matrix supporting 4K@60Hz (4:4:4) HDMI. It enables
any one of the 4 HDMI sources to any one of the 4 HDMI displays, and with Phoenix and
Coaxial ports for audio extraction. As well as supporting multiple control modes, such as
front panel buttons with display, IR, RS232 and TCP/IP control
Features
18Gbps (4K 60Hz 4:4:4), HDR10, HLG, Dolby Vision and HDCP 2.2 support
PCM2.0, Dolby True HD and DTS-HD master audio, LPCM7.1 pass through with S/PDIF
and analogue stereo extraction
IR, RS232,TCP/IP, comprehensive web GUI and front panel menu LCD control
Ultra compact product housing
Package Contents
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact your distributor for a replacement.
1
x
Main
Unit
(PT-MA-HD44M)
1
x
Power
Adaptor
(
12
V
2A
)
1
x
Remote
control
1
x
IR
Ext
RX
Cable
5
x
Phoenix
3
pin
for
RS232
cable termination & L/R Audio
termination
1
x
User
Manual
Specifications
Operating Temperature 0
℃
to+40
℃
Operating Humidity 5 to 90%RH(No Condensation)
Max resolution 4K@ 60hz YUV4:4:4
HDCP Compliant HDCP2.2 and HDCP1.4
Output Video HDMI2.0 and HDMI 1.4
Audio Format Supported PCM2.0,Dolby True HD and DTS-HD master audio, LPCM7.1
RS-232 serial port 3PIN Phoenix connector
Ethernet port (IP control) RJ45, female
IR Ext port 1x3.5mm stereo jack
Bandwidth 18 Gbps
Default IP 192.168.1.168
Dimensions(WxHxD)
L216.2XW128.5XH34mm
Net
Weight
0.47kg
Power
consumption
14W(Max)
