FEATURES
⚫
IP44-rated weatherproof design: Resistant to extreme conditions including intense sunlight, humidity,
rain, and dust.
⚫
Optimized audio performance: 3” /5” /8” high-output woofer with wide dispersion for clear sound in open
spaces and large venues.
⚫
Durable construction: Gold-plated terminals with anti-corrosion coating for long-term reliability.
⚫
Flexible mounting: Quick-install brackets included for vertical or horizontal positioning.
⚫
Aesthetic options: Sleek enclosures available in classic black or white finishes.
⚫
System integration: Built-in 100V line transformer for seamless compatibility with commercial audio
systems.
Installation
⚫
All speakers must be connected to a constant voltage line. The amplifier power should be equal to or
greater than the total power of all connected speakers.
⚫
The output power can be adjusted using the control located at the rear of the speaker.
⚫
Ensure that the transformer setting is equal to or lower than the nominal power supplied by the
amplifier.
⚫
For standard residential systems requiring 8-ohm speakers, set the dial on the rear of the speaker to 8
ohms and connect it to the receiver.
Specifications
Limited one-year warranty
Pure Acoustics products have been designed and manufactured to the highest quality standards. However,
in the event that something malfunctions, Pure Acoustics and your local authorized distributor warrant free
of charge parts and labor (some exclusions may apply) for a period of one year. This warranty is only valid
for the original owner. This warranty is limited to the repair of the product. This warranty will not apply to
units that were subject to misuse, neglect, abuse, alteration or improper installation. This warranty will not
cover damage due to fire, water, heat, lightning or any other cause beyond the control of Pure Acoustics.
Retention of your original dated receipt is required in order to obtain warranty service from your local
authorized Pure Acoustics Dealer.
Item
Blyss 603T
Blyss 605T
Blyss 608T
Nominal Power (Ohmic
mode)
20W
60W
100W
Power (100V line mode)
2W/4W/8W/12W
4W/8W/16W/30W
7.5W/15W/30W/60W
Impedance
8 Ω
8 Ω
8 Ω
Woofer
3” Polypropylene
5” Polypropylene
8” Polypropylene
Tweeter
1” Mylar
1” Mylar
1” Dome
Frequency response
100Hz-20KHz
60Hz-20KHz
45Hz-20KHz
IP Rating
IP44
IP44
IP44
Sensitivity
83dB (±2dB)
89dB (±2dB)
90dB (±2dB)
Bracket
Aluminum
Aluminum
Grill
Aluminum
Aluminum
Aluminum
Terminals
Cable clamps up to Ø5mm (0.2 inch) conductor
Dimension (HxWxD)
165*115*165mm
256*167*218mm
360*240*254mm
Weight (per pair)
2.1kg
5.6kg
13.3kg
