24

™

534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com

Video Mode: Congure assorted video output

settings.

SDI-3G Mode: Set the SDI level. Options

include: Level-A, Level-B

Video Output: Set the video output to

SDI or HDMI. Options include: HDMI, SDI

DVI Mode: dene HDMI Data Transfer

type.

Options include: HDMI, DVI

Other:

Auto Inversion: Toggle auto inversion.

Options include: O, On

Tally Mode: Toggle ability to acknowledge Tally

Light command. Options include: O, On

USB Audio: Toggle USB audio

embedding. Options include: O, On

USB2.0 Function: Dene how the USB

port is used. Options include: UVC, Host

Display Info: The ability to display OSD mes-

sage overlays on the video output.

Communication Setup

Move the main menu cursor to

[Communication Setup] and press the

[HOME] key enter the Communication

Setup page, as shown in the following

gure.

Communication Setup

Protocol VISCA

V_Address 1

V-AddrFix O

Net Mode Serial

Baudrate 9600

[Menu] Back

Protocol: Control protocol Options include:

VISCA, PELCO-D, PELCO-P, Auto

V_Address: VISCA protocol camera address

Options include: 1 ~ 7

V-AddrFix: When enabled, the Visca address will

not change. Options include: O󰀨, On

Net Mode: Control type Options include: Serial,

Parallel

Baudrate: Baudrate control speed Options

include: 2400, 4800, 9600,

38400

P_D_Address: Pelco-D protocol

address Options include: 0 ~ 254

P_P_Address: Pelco-P protocol

address Options include: 0 ~ 31

Restore Default

Move the cursor to the “Restore Default”

option and press the [Enter] button to

enter the Restore Default page, as shown

in the gure below.

Restore Default

P/T Limit Reset

Press [Enter] Conrm

Press [Back] Cancel

Select [Enter]

[Menu] Back

Note: Press the [Enter] button to conrm.

All camera parameters will return to

default, including IR remote & VISCA

Addresses.
