11

™

Communication Interface

▪ 1x 8-pin Mini DIN RS232 Input, Max distance: 98.5ft / 30m,

Protocol: VISCA / Pelco-D / Pelco-P

▪ 1x 8-pin Mini DIN RS232 Output, Max distance: 98.5ft / 30m,

Protocol: VISCA / Pelco-D / Pelco-P

▪ 1x 2-pin Phoenix port RS485 Input / Output, Max distance:

3,937ft / 1200m, Protocol: VISCA / Pelco-D / Pelco-P

IR

4x IR Addresses, Max distance 30ft / 9m

Power Jack

JEITA Type (DC IN 12V)

Physical Parameter

Input Voltage DC 12V / PoE+(802.3af)

Current Consumption Max 2A

Operating Temperature 14°F ~ 104°F (-10°C ~ 40°C)

Storage Temperature -40°F ~ 140°F (-40°C ~ 60°C)

Humidity Range 10% - 80%

Power Consumption Max 18W

Size in. (W x D x H) (12X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91” with tilt

up) H

(20X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91”

with tilt up) H

(30X) 6.69” W x 7.12” (7.75 with SDI) D x 8.98” (10.5” with tilt

up) H

Size mm. (W x D x H) (12X) 141.5 W x 151 (169 including SDI) D x 176 (201 with

tilt up) H mm

(20X) 141.5 W x 151 (169 including SDI) D x 176 (201 with

tilt up) H mm

(30X) 170 W x 181 (196.85 including SDI) D x 228 (266.7

with tilt up) H mm

Camera Weight (12X) 3.25 lbs | 1.47 kg

(20X) 3.25 lbs | 1.47 kg

(30X) 4.41 lbs | 2.0 kg
