Installation instructions
AS-7000 central unit (receiver) (fig. CENTRAL UNIT)
Please proceed as follows to install the receiver:
1. Insert the power plug from the exhaust air device into
the socket on the AS-7020/30/40 central unit.
2. Attach the corresponding protective cap
(S plug-guard) over the plug on the exhaust air
device and screw it in place. If it is not possible to
install the plug guard with the plug inserted then it
may be necessary to adjust the edges of the plug
guard slightly or to have an electrician attach a
different plug.
3. Connect the AS-7020/30/40 central unit to the
power socket (power source). Following an internal
self-test the power LED will light up green and
operational readiness is signalled with a beep.
(For further information on flashing and beeping
patterns please see the status and error reports.)
Installation instructions for the
window transmitter
AS-F20 and the magnet (9 and 14)
Some points need to be explained and followed in
order to install the window transmitter and the
magnet to the top window frame and to the window
casements. The distance around all sides of the casing
parts must be less than 6 mm and the minimum
NOTE
The teaching of the sensors (window transmitter,
stove transmitter and roller shutter transmitter) in
connection with the central unit must be carried out
or tested before initial operation of the exhaust air
controller. If the exhaust air controller is installed
incompletely (e.g. without the relevant plug guard
in figure S) or if it has been taught incorrectly
before being connected to the socket a protect
function will be activated and it will not be possible
to operate the exhaust air system.
CAUTION!
The roller shutter must be open when the exhaust
air device is in use or it must be fitted with an
additional roller shutter sensor AS-R40. If the roller
shutter is closed it is not possible to ensure sufficient
replenishment of fresh air.
INSTALLATION
NOTE
Note: Before installation, carry out the coding of the
components and check the function of the exhaust
air control (see page 38).
We recommend having the device installed by an
installation technician and heating engineer or by an
electrical installation technician. Correct installation
guarantees the long term, safe operation of the
exhaust air controller. The regional chimney sweep
can and should carry out a function test.
EN
29
