7
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be sure to do the following things:
1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Place the spacers (not included) in the corresponding bracket holes.
CAUTION:
• When you attach the mount, be sure to use the spacers ( provided by the third-party
manufacturer ) between the TV and the bracket.
• To prevent internal damage to the TV and ensure it is mounted securely, be sure to use fixing
screws (not provided) that are 16mm and 10 mm in length when measured from the attaching
surface of the mounting hook.
Top: 16mm (max depth) x 2pcs
Bottom: 10mm(max depth)x 2pcs
Wall mount hole pattern VESA (mm)
200 × 200
Wall mount screw size (mm)
M6
Follow instructions provided with the wall mount bracket.
• To complete the installation, please contact the wall mount manufacturer or the retailer from
which you purchased the TV.
16mm and 10 mm
Wall mount bracket
Screw
Spacer
Rear cover of the TV
