Promise Technology VESS A7800 Handleiding (108 Pagina's)

Handleiding

3

Model Vess A7600 Vess A7800

RAID

RAID Levels Supported 0, 1, 1E, 3, 5, 6, 10 (0+1), 30, 50, 60

Hot Spares Multiple global or dedicated hot-spare drives with revertible option

Maximum LUNs per

System/Array

256/32

Software

Supported OS (64-bit) Windows 10 in default. Windows Server 2012/2016R2

Management

Graphical UI/SNMP via Ethernet, CLI/CLU via Ethernet, OPAS Service via

USB, IPMI, SDK or API

Event Notication Email, SNMP, Buzzer, LEDs

System

AC Input 100 ~ 240 VAC, 60 ~ 50Hz

Current (Maximum) 8-4A ( 550W, 8A/100V, 4A/240V) , 10A ( 800W-Vess A7800 )

Power Supply

550W (1+1@550W) in default.

1100W (2+1@550W) optional

1100W (2+1@550W) in default.

1600W(2+1@800W)

Fan Non-swappable

Temperature 5° ~ 40°C (-40° ~ 60°C non-operational)

Relative Humidity

Operational: 10% to 80% (Non-Condensing)

Non-Operational: 10% to 95% (Non-Condensing)

Dimensions (H x W x D) 131 x 447 x 503mm 173 x 447 x 503mm

Safety/EMI CE, FCC, VCCI, BSMI, RCM, CB, KCC, TUV CB, cTUVus

Warranty 3 years limited warranty
