reMoving tHe Power suPPly unit

Toremoveafailedpowersupply,pleaserstidentifythefailedpowersupply.

1. Holdontothepowersupplyhandlewhilepressingthelockinglevertowardsthepowersupplyhandle.

2. Pulltoremovethepowersupplyfromthechassis.

1. Before replacing the power supply, power off the server, unplug

the power cord, and disconnect all wiring from the power supply.

2. In a redundant system, you do not need to power down the

server.

replacIng a power Supply

Before proceeding with a power supply replacement, make sure you have the correct type of power supply

usedforthereplacementunit.All power supplies must be the same make and model in order to avoid unit

malfunction or failure.

TheVessA7600systemscanaccommodatetwoACpowersuppliesinthebayattherearofthechassis.The

VessA7800systemscanaccommodatethreeACpowersuppliesinthebayattherearofthechassis.Eachunit

providesupto550Wattsofpower.Onlyasinglepowersupplyisrequiredforoperation,withthesecondpower

supplypurelyasaredundant,load-sharingbackup.Itcanberemovedwithoutaffectingsystemoperation.

InstallingandRemovingthePowerSupply

1. Alignthepowersupplyunitwiththepowersupplyslot.EnsurethattheLEDappearsontheleftwhenyou

areinstallingthepowersupplyunit.

2. CarefullyslidethePSUallthewayintothepowersupplybayuntilitclicksintoplace.

75
