Mounting Vess A3340 in a rack

The instructions here apply to the Vess A3340 2U form factor model.

Cautions

• DonotliftormovetheVessA3340unitbythehandlesontheear

bracketsinfront.Holdthesystemitself.

• DonotinstalltheVessA3340unitintoarackwithoutrailstosup-

portthesystem.

• Onlyaqualiedtechnicianwhoisfamiliarwiththeinstallationpro-

cedureshouldmountandinstalltheVessA3340unit.

• Mounttherailstotherackusingtheappropriatescrewsandange

nuts,fullytightened,ateachendoftherail.

• Donotloadtherailsunlesstheyareinstalledwithscrewsasin-

structed.

•

TherailsavailablefortheVessA3340unitaredesignedtosafely

supportthatVessA3340unitwhenproperlyinstalled.Additional

loadingontherailsisatthecustomer’srisk.

• ThemountingrailswillsupportyourVessA3340unitonlyifin-

stalledasinstructed.

• Donotinstallharddiskdrivesinthesystemuntilafterplacingthe

systemintherack.

The Vess A3340 installs in a 19” equipment rack. Please examine the illustrations in this section to make sure

you are using the correct type of rack.

In order to place the system in the rack, rst attach the ear brackets to the front of the device. Then install

the sliding rail system in the rack. Finally place the device on the sliding rails and secure it to the rack. Use only

the screws and fasteners included with the shipment of the sliding rail system, or with the Vess A3340. This

procedure is described and illustrated in the sections that follow below.
