Vess A3340 rear panel connections

Access to physical data and management connections are located on the rear panel of the Vess A3340.

Feature Description

HDMI

Provides video out connection for HDMI enabled monitors used to view the management

interface using CLI, CLU or WebPAM PROe.

VGA

This is also used for a video out connection for VGA monitors, it is also used to view the

management interface using CLI, CLU or WebPAM PROe.

USB

The rear panel features two USB 2.0 and two USB 3.0 ports. Use to connect to a USB key-

board for managing the Vess A-Series, or use it to transfer data to or from a USB memory

device.

RS-232

Serial port can be used for two different functions:

1. Use for the controlling line connection to an uninterruptible power supply (UPS).

2. Use to connect to analog cameras using the analog camera input cable.

Audio In

Use for input from a peripheral audio device, such as a microphone. Plug-In Power micro-

phones are supported.

Audio Out Use for output (line out) peripheral audio device (speakers, for example).

9

IntroductionVess A3340s / Vess A3340d / Vess A3340 PoE
