The adjacent furniture and all materials used in the installation must be able
to withstand a minimum temperature rise of 85°C above the ambient
temperature during operation.
An oven must have forced ventilation to install the hob above it.
Fitting the hob into the worktop
Bottom view
1. Remove the pan supports, the burner
cap and crown and carefully turn the
appliance upside down and place it on a
cushioned mat.
Take care that the ignition devices and
flame supervision devices are not
damaged in this operation.
2. Apply the sponge provided around the
edge of the appliance.
3. Do not leave a gap in the sealing agent
or overlap the thickness.
Do not use a silicon sealant to seal
the appliance against the aperture.
This will make it difficult to remove the
appliance from the aperture in future,
particularly if it needs to be serviced.
1. Place the brackets over the holes that
match the size of the screws. There are
one set of screw holes in each corner of
the hob.
Attach the brackets to the hob by slightly
tightening the screws through the bracket.
8
