Model 15162 can be controlled both from the device's control panel
and using a remote control.
Use the device for any other purpose is absolutely prohibited.
Neither the manufacturer nor its representatives accept any
liability for consequences of improper operation or
intentional misuse, including direct or indirect damage and
loss of business.
ATTENTION! The device is not a measuring device as defined in
the Metrology Act.
DELIVERY KIT:
ź Rotary laser level - 1 pc
ź - 1 pcRemote control
ź Laser beam detector - 1 pc
ź Detector bracket - 1 pc
ź Laser enhancing glasses - 1 pc
ź - Target plate for the laser 1 pc
ź - 1 pcCharger
ź Transport case - 1 pc
ź Operation manual - 1 pc
DEVICE PARTS:
The numbering of device elements refers to the drawing on pages 2-3
of the instruction manual:
Fig. A 1. Laser module
2. Control panel
3. Charging port cover
4. Handle
5. Tripod port
6. Charger
7. Remote control
8. Laser beam detector
9. Detector bracket
10. Target plate for the laser
11. Laser enhancing glasses
12. Aluminium tripod PROLINE 15164*
13. Telescopic grade rod 5 m PROLINE 15163*
Fig. B 14. On/off switch
15. Operating mode
16. Shock safety
17. RPM setting
18. Beam angle (scan function)
19. Direction of rotation
20. Slope setting
* The accessories shown or described are not standard
equipment. For the complete offer of auxiliary equipment, see
our catalogue.
TECHNICAL PARAMETERS:
PREPARATION FOR WORK:
ATTENTION: Inspections, adjustments, and procedures other than
those described in the manual may cause exposure to hazardous
radiation.
Before each use, make sure to check the level for any damage (e.g.
whether its housing is not cracked or its elements are not broken). If
any damage is found, take the device to a service centre to check that
it is safe to use.
n How to charge the battery
The product has an integrated nickel metal hydride battery (Ni-MH)
Nominal voltage 5.0 V
Battery type Ni-MH
Maximum range (with detector) 30 m (500 m)
Battery capacity 3500 mAh
-1
RPM 0 / 60 / 120 / 300 / 600 min
o o o o o
Scan angle 0 / 10 / 45 / 90 / 160
Laser accuracy ±1mm / 10 m
Remote control range about 20 m
o
Auto-levelling range ±5
o o
Operating temperature range -10 C ~ +45 C
Maximum operating time 20 h
Resistance class IP 54
Tripod thread 5/8-11 UNC (15,9 mm)
Laser beam green
Class laser 3R
Laser wavelength 520 nm
Laser output power 1.28 mW
Weight 1.85 kg
Laser beam detector
Nominal voltage 9 V d.c.
Battery type 9 V 6F22
Weight (without battery) 0.16 kg
Remote control
Nominal voltage 3 V d.c.
Battery type 2 x1,5V AAA LR03
Weight (without battery) 0.042 kg
Battery charger
Input voltage 100 – 240 V a.c.
Input frequency 50 / 60 Hz
Input current 0,2 A
Output voltage 5,6 V d.c.
Output current 700 mA
Rated power 6,5 W
Insulation class /II
Weight 0.1 kg
Level
Equipment class III
