16
SYSTEM
System type Portable Powered 2.1 System with Two Line Array Tops and One Subwoofer
Maximum SPL Output 128 dB peak system output (pink noise)
Frequency Response (-10dB) 38Hz – 20kHz
SPEAKERS
LF Driver 2 x 10” (254mm) woofer in Bass-Reex conguraon
HF Driver 12 x 3.25” (82mm) neodymium drivers (6 for each TOP)
Coverage Paern 120° x 60°
AMPLIFIER
Type Class D with SMPS
System Power Rang 600 Was LF, 2x300 Was HF Connuous, 2400W Peak
Channels 2 MIC/LINE selectable inputs
Connectors 2 x COMBO (INPUTS), 2 x XLR-M (LINK), 2 x SPEAKON (POWER OUTPUTS)
Controls 1 x LCD with Data Encoder
Processing 24bit / 48KHz CORE DSP: 2-band EQ, Selectable CONFIGURATION and EQ PRESETS, Digital Liming
Wireless Audio Bluetooth built-in receiver
GENERAL SPECIFICATIONS
Cabinet Material Plywood
Finishing High-strength polyurethane black paint
Grille Powder coated perforated steel with an-dust screen
Handles 2 x sides (SUB)
Pole Socket 1 x top M20 (SUB), 1 x boom 35mm (TOP)
Included Accessories M20 / 35mm telescopic pole, 4-wire SPEAKON/SPEAKON cable, 2 x SAT cover
Dimensions (W x H x D) TOP: 112x616x132 mm
SUB: 420x580x490 mm
Weight TOP: 4.5 kg (9.9 lbs) (2x)
SUB: 26.5 kg (58.4 lbs)
SYSTEM: 35.5 kg (78.2 lbs)
Power Supply 230 V~ or 120 V~ - 50/60 Hz with LINE VOLTAGE selector
Rated Consumpon 480 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
