18
USRMAN_AE604EN_REV003
5.3 Menu Description And Navigation
Using the keyboard on the front panel
From the home screen where the display shows the general status, press OK to access the menu structure.
The OK key in the sub-menus is used to confirm the selection of the element pointed by the navigation arrow.
Use the UP and DOWN keys to scroll the list of menus and sub-menus.
Press OK to access the menu or sub-menu pointed by the navigation arrow.
Press BACK to go back to the previous menu or cancel the selection of a function. Repeatedly pressing the BACK key
from any workstation returns to the main screen.
Alternatively, you can access the selected menu or sub-menu by pressing the RIGHT key, and go back to the previous
menu or sub-menu by pressing the LEFT key.
The main menu is structured in the form of a list in which the functional parts of the system are managed:
Menu tree:
• Line & Amplifiers Management of speaker lines and amplifiers
• Power supply & Battery Management of primary power supply (230V) and secondary (Battery)
• Fire microphone Management of the emergency microphone workstations
• Recorded messages & SD Management of pre-recorded messages on micro-SD card
• Input contacts Management of contacts to launch messages
• Alarm Buttons Management of Alarm – Evacuation frontal buttons
• Ethernet Management of ethernet connection
• System status & Conf System configuration
• Volumes Volumes configuration
• Message Scheduler Configuration of hourly programming of pre-recorded messages
• System Logs Display of system events
• Access level login User authentication
