CLICK & CLEAN - CLEANING THE GLASS
1. After removing the door and resting it on a soft
surface with the handle downwards, simultaneously
press the two retaining clips and remove the upper
edge of the door by pulling it towards you.
2. Lift and firmly hold the inner glass with both hands,
remove it and place it on a soft surface before
cleaning it.
3. Refit the intermediate pane (marked with “1R”)
before refitting the inside pane: To position the panes
of glass correctly, make sure that the “R” mark can be
seen in the left-hand corner. First insert the long side
of the glass marked “R” into the support seats, then
lower it into position. Repeat this procedure for both
panes of glass.
4. Refit the upper edge: A click will indicate correct
positioning. Make sure the seal is secure before
refitting the door.
REPLACING THE LAMP
Disconnect the oven from the power supply, unscrew the cover from the light, replace the bulb and screw the
cover back on the light.
Reconnect the oven to the power supply. Do not use the oven until the light cover has been refitted.
Please note: Use 25 W/230 V type G9, T300 °C halogen lamps.
The bulb used in the product is specically designed for domestic appliances and is not suitable for general room lighting
within the home (EC Regulation 244/2009).
Light bulbs are available from our After-sales Service. - Do not handle bulbs with your bare hands as your ngerprints
could damage them. Do not use the oven until the light cover has been retted.
