PN: 545-507_EN 5
Rev: B
Updated: 2/11/25
UNBOXING
Remove the unit from the carton and inspect for signs of damage. If there is damage to the unit:
• Notify the carrier within 24 hours of delivery,
• Save carton and packaging materials for inspection purposes,
• Contact your local dealer, or if purchased directly, contact MarmonLink Customer Care team @ 1-866-275-6392
CAUTION
All electrical connections must be in accordance with local electrical codes and any other applicable codes.
WARNING
Disconnect all power before attempting installation
LOCATION
When installing this unit, the ambient temperature at the mounting site should not exceed 100°F (38°C)
The unit must be sealed to the counter. Apply a continuous bead of NSF International (NSF) silicone sealant (Dow 732 or equal)
approximately 1/4-inch around the outside of the unit. All excess sealant must be wiped away immediately.
ELECTRICAL
Product requires a dedicated 120V 1-Phase 20A capacity grounded receptacle with matching plug configuration.
MINIMUM UNIT CLEARANCES
STACKING
Holding Bin is not load-bearing. Do not place another unit or other weight on top of the unit
PASS-THRU OPTION
Unit is designed to convert as a Pass-thru unit. See
Parts List on page 22 for pan, trivet and lid part
numbers.
• Loosen screws holding pan stop brackets
• Lift bracket up to remove
• Retighten screws
INSTALLATION
Front Sides Rear Top
24” (61cm) 0” (0cm) 1.5” (3.8cm) Open
