Mount the furniture door to the
front of the was
her using the
hinges. Place the spacers
under the hinges (I)
and then
fix in position with screw (H).
!
Slide the washer into an
opening of the size indicated in
the diagram opposite. A furniture
plinth may be run across the front
of the appliance, but its height will
be dictated by the height the
washer is set at.
!
The 4 adjustable feet allow the
height of the washer to be
adjusted from 820 mm to a
maximum of 84
0 mm. To adjust
the height, you should remove
the nuts fitted to each foot and
replace these with the 5 mm
nuts supplied. Raise the feet to
your desired height and then
fully tighten the lock nut to the
base of the washer.
570
596
600
min.
600
H
I
820
min.
825
min.
We suggest mounting the
furniture door so that it opens
towards the left, which is the
same direction as the porthole
door. This will leave more
space when you are loading
washing into the appliance.
2
8
