11
5 Customizing Speaker Settings
5.1 Speaker Net Browser
Worx Control
Software Reference Manual
5 Customizing Speaker Settings
Inside a Venue preset, you have the option to manage speakers individually or as
groups. It is important to note that once a speaker is added to a group, all individual
settings are reset and the grouped speakers are all changed simultaneously.
5.1 Speaker Net Browser
Once you’ve created a new Venue preset, you will be taken to the Speaker Net
browser. From this page you can view all speakers on your network, give them
custom names, edit each speakers’ EQ and dynamics, and begin designing your
group.
If you do not see all the speakers on your network, click the Rescan button.
Power User Tip: You do not have to create a speaker group for any or all of your speakers.
Any loudspeaker in the Speaker Net browser can be edited, monitored, and controlled
from the browser.
5.1.1 Performance Monitoring
Each loudspeaker icon features several performance-monitoring indicators:
Metering
Input. This meter displays the level of the incoming signal to your loudspeaker.
Clip. The right-most indicator will illuminate red when the signal going to the
analog-to-digital converter (ADC) on the loudspeaker exceeds 0 dB. At this level,
the signal will begin to overload the converter and exhibit signs of clipping, an
undesirable type of distortion.
Limit. The indicator to the left of the Clip light will illuminate yellow when your
loudspeaker’s protection limiter has been engaged.
Thermal
This indicator monitors the temperature of the amplifiers. It will not illuminate while
the temperature is within normal operating limits (less than 147˚ F/63.9° C). It will
illuminate yellow when the temperature rises to dangerous level (147 – 152˚ F/63.9
– 66.7° C). It will illuminate red when the temperature rises to a level where your
loudspeaker will be severely damaged (over 153˚ F/67.2° C).
Note: If this indicator turns yellow or red, power off your loudspeaker immediately and let
it cool down. Your loudspeaker should not exceed thermal limits during normal
operation. If it does, you may need to contact PreSonus to arrange for a repair.
