59
13 The Settings Page
13.7 Digital Patching (StudioLive Series III only)
Universal Control for StudioLive
®
Mixers
Software Reference Manual
13.7 Digital Patching (StudioLive Series III only)
Digital patching allows you to route any analog or digital input to any channel and any mix to any output. This
can save you hours of frustration having to rewire and repatch your physical inputs and outputs, especially
in a fixed installation. Digital patching also allows you to freely route audio to your AVB network and record
anything you’d like via USB.
Press the Master Reset to reset all routings to their default state.
13.7.1 Input Source
Selecting the Input Source tab will allow you to patch any source type to any channel. This also provides you
with a global view of what type of source is routed to each channel, as well as allows you globally configure
all of your source routings for each type. For example, while the USB tab is active, you can patch every
desired USB return to every channel on your mixer.
13.7.2 Input Patch
From the Input Patch tab, you can route any input to any channel. This allows you to select the sources for
all input types (Analog, AVB, USB, and SD). From this menu, you can, for example, route Analog Input 10 and
USB Return 17 to Channel 1 on your mixer. You can then toggle between the two sources using the USB and
Analog source controls for your mixer.
Pressing the Reset Sends button will reset the default routing.
Power User Tip: The routing you select for each source type is saved. In this way, you can switch between
custom Analog, Network, and USB routings just as you can with the default routings.
