1
1 Introduction
1.1 About This Manual
Universal Control for StudioLive
®
Mixers
Software Reference Manual
1 Introduction
Universal Control is a powerful software application that provides control of channel, subgroup, aux, and bus
levels; Fat Channel parameters; aux mixes; effects; and graphic EQs. It also provides a visual overview of your
StudioLive® settings so that you can see, adjust, and organize them, as well as a library, allowing you to easily
manage your presets and scenes.
For StudioLive Series III and AI-series console mixers, Universal Control provides bidirectional control that
allows you to remote-control mixing functions that are also available from their respective hardware control
surfaces. Since control is bidirectional, fader moves and parameter changes made on the StudioLive mixing
surface are reflected in Universal Control and vice versa.
For StudioLive Series III rackmount mixers and StudioLive AI-series RM and RML mixers, Universal Control
provides software-only control. The StudioLive CS18AI hardware controller for StudioLive AI-series RM/RML
mixers can be used in conjunction with Universal Control.
Universal Control will run on macOS, Windows, and Windows Touch computers, as well as Android devices
and iPads, affording flexible control options for any mix situation.
To use Universal Control, you must do one of two things:
y Connect your StudioLive, computer, Android device, or iPad to the same wireless network. This option
will allow you to use any or all of these devices to remote control your StudioLive mixer anywhere in
the venue.
y Connect and sync your StudioLive to your computer using your computer’s host transport (USB, FireWire
s800, or Thunderbolt). This option allows you to use Universal Control while recording and playing back
audio through Capture™, Studio One Pro®, or a third-party DAW of your choice.
Note: StudioLive AI-series mixers support the use of the Apple Thunderbolt to FireWire adapter.
1.1 About This Manual
We suggest that you use this manual to familiarize yourself with Universal Control before trying to use it to
control your mixer. This guide assumes that you have followed the networking procedures outlined in the
Networking for StudioLive Remote Control Guide. Please refer to the Using Your StudioLive as an Audio
Interface with Universal Control Reference Guide for installation instructions.
Throughout this manual, you will find Power User Tips. These tips provide useful hints on how to best use
Universal Control and take advantage of unique workflow functions and features.
For the most part, StudioLive Series III and AI-series console and rack mixers behave identically. Because of
fundamental architectural differences, some functionality is not available in every series and style of mixer.
When these differences occur, it will be noted as follows:
y StudioLive Series III mixers. All StudioLive Series III console and rack mixers.
y StudioLive Series III console mixers. StudioLive 64S, StudioLive 32S, StudioLive 32SX, StudioLive 32SC,
StudioLive 32, StudioLive 24, and StudioLive 16
y StudioLive Series III rack mixers. StudioLive 16R, StudioLive 24R, and StudioLive 32R
y StudioLive AI-Series mixers. All StudioLive AI-series console and rack mixers.
y StudioLive AI-Series console mixers. 16.4.2AI, 24.4.2AI, and 32.4.2AI
y StudioLive AI-Series RM/RML mixers. RM16AI, RM32AI, RML16AI, and RML32AI
1.2 Companion Manuals
This guide explains the functions and basic routing features of the audio interface onboard your StudioLive
mixer. The following companion guides are also available:
1.2.1 Hardware Manuals
y StudioLive Series III Console Mixer Owner’s Manual. Use this reference guide to understand all the
hardware functions on your StudioLive Series III console mixer (StudioLive 64S, StudioLive 32S,
StudioLive 32SX, StudioLive 32SC, StudioLive 32, StudioLive 24, and StudioLive 16).
y StudioLive Series III Rackmount Mixer Owner’s Manual. Use this reference guide to understand all the
hardware functions on your StudioLive Series III rackmount mixer (StudioLive 32R, StudioLive 24R,
StudioLive 16R).
y StudioLive AI-Series Console Mixer Owner’s Manual. Use this reference guide to understand all the
hardware functions on your StudioLive AI-Series console mixer (StudioLive 32.4.2AI, StudioLive
24.4.2AI, StudioLive 16.4.2AI).
y StudioLive AI-Series Rackmount Mixer Owner’s Manual. Use this reference guide to understand
all the hardware functions on your StudioLive AI-Series rackmount mixer (StudioLive RM/RML32,
StudioLive RM/RML16).
