front door plate
Fig.2-9
tant
oven door
noise filter
current-resis
constructure
washer to keep a good earth.
six-angle screw
oven
hinge(up)
Fig.4-2
door hook
latch switch
pilot switch
latch switch holder
latch switch holde
latch switch
pilot switch
door hook
（a）
Fig.4-3
（b
）
r
4
4
.
.
2
2
T
T
H
H
E
E
D
D
O
O
O
O
R
R
C
C
O
O
M
M
B
B
I
I
N
N
A
A
T
T
I
I
O
O
N
N
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
1.
2.
3.
To disassemble,
Pull out the power plug.
Take off the cabinet.
Loosen the two six –angle screws of left hinge (up)
with a s
ocket wrench (FIG.4 - 2).
Push the door release button to have the hook out
(FIG
.4 -3).
Pull the hinge with the door out of the oven
togethe
r, and take off the washer of the hinge (low)
shaft (FIG.4 - 2).
Pick up the ten inverse hooks which around the
cove
r with a small screwdriver
carefully(ATTENTION: the cover is made of
plastics, and is very liable to be broken), and take out the cover.
Take off the two screws at the door side
w
ith a “+”-screwdriver
Take off the hinge (up)(FIG.4- 2).
Apart the doorframe from the doorplate
(FIG
.4-2).
Take off the hook spring with a pointed
plier
, then the hook combination.
Clamp the window plate with hand, push it
down a
ccording to the arrow direction,
and take it off.
To assemble the door combination(see sketch
4-2 to 4-5)
Apply proper silicon grease or lubricating
gre
ase on the “★” mark of the hook first, then fix the hook on the oven door, and the spring on its place
(FIG.4 - 5), check whether the hook is operating in normal.
Apply proper silicon grease or lubri
cating grease on the “★” mark of the hinge (UP), install the hinge (UP) in
the hole at right above of the door as FIG.4 - 2, then install the window on the door as FIG.4 - 1, make sure
the hook won’t out. Then tighten each hook on the window to the trough of the door. After assembled, check
whether the door hook is working in normal.
Tear off the back protective paper of the window, then the sides of adhesive t
ape as FIG.4 – 1, and stick it on
