Page 7



Unit Speciﬁcations and Features

Unit

Speciﬁcations

and Features

Indoor unit display

Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit

may be slightly different. The actual shape shall prevail.

NOTE: Different models have different front panels and display windows. Not all the display codes

describing below are available for the air conditioner you purchased. Please check the indoor display

window of the unit you purchased.

Display Code

Meanings

Power Cable (Some Units

(A) (B)

)

Remote Control

Remote Control Holder

(Some Units)

Functional Filter

(On Back of Main Filter - Some Units)

Louver

Front Panel

“ ” when Active Clean feature is turned on(For Inverter split type)

fresh defrost run timer

Display window

Displays temperature, operation feature and

error codes:

“ ” for 3 seconds when:

• FRESH, UV-C lamp, SWING, TURBO, ECO,or SILENCE feature is turned on

“ ” when Fresh and UV-C lamp(if any)feature is activated(some units)

“ ” for 3 seconds when:

• TIMER OFF is set

• FRESH, UV-C lamp, SWING, TURBO, ECO,or SILENCE feature is turned off

“ ” when defrosting

when unit is self-cleaning(For Fixed-speed type)

“ ” when 8 C heating feature is turned on(some units)

“ ” when defrost feature is activated.

“ ”

“ ” when the unit is on.

“ ” when TIMER is set.

fresh

defrost

run

timer

“ ” when Wireless Control feature is activated(some units)

• TIMER ON is set (if the unit is OFF, remains on when TIMER ON is set )

“ ”
