Installing the magazine
Attach the magazine in the reverse manner to removing it. Make sure that the guide rails do not
twist when inserting the magazine. Also make sure that the retaining pawl (4) is fully engaged by the
spring force. Push the magazine up to the stop buffer by exerting slight pressure on it. If this does not
work, loosen the lock nut (3) and readjust the position of the stop buffer with the thread. Then
tighten the nut again.
The procedure for changing the magazine is the same for all magazine types.
Which magazines can be used are shown in the overview below:
Magazine design
PREBENA staples
Type Z50
Z50
Type Z55
Z55
Type Z64
Z64
