w ww.practixx.com
GB
|
49
15. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions.
The customer‘s mains connection as well as the
extension cable used must also comply with these
regulations.
Use a portable safety switch (PRCD) if the residual
current protective circuit (RCD) in the mains power
supply is not provided with a rated residual current
of no more than 30 mA.
The mains power connection is protected with a 16
A slow-blow fuse.
Damaged electrical connection cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnected
from electrical power when checking for damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the designation H07RN-F.
The printing of the type designation on the connection
cable is mandatory.
• The product fulls the requirements of EN 61000-
3-11 and is subject to special connection require-
ments. This means that use at any freely selectable
connection points is not permitted.
• The device can cause temporary voltage uctua-
tions in unfavourable mains conditions.
• The product is only intended for use at connection
points that
13. Storage
Note
Move the splitting column into the bottom position (see
section 11.7).
Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the product in its original packaging. Cover the
product to protect it from dust or moisture. Store the
operating manual with the product.
14. Transport
m Attention!
Disconnect the mains plug before transport.
m Attention!
Do not transport the device lying on its side!
Note
Move the splitting column into the bottom position (see
section 11.7).
14.1 Transport with transport handle (1) (Fig. 18)
The log splitter is equipped with two transport wheels
(13), a support wheel (25) and a transport handle (1) for
easy transport.
1. In order to transport the device, hold the transport
handle (1) with one hand and tilt the log splitter
slightly with your foot.
2. The log splitter tilts on the support wheel (25) and
the transport wheels (13) and can thus be moved
away.
14.2 Transport by crane (Fig 19)
m Attention!
Never lift on the riving knife!
1. Attach the transport straps (not included) to the
upper bracket (16a) of the guard rail (16) and to the
bracket of the log lifter lock (26).
2. Lift the device up carefully.
