1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the
electrical regulations not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes and
for increasing the reliability and extending the service
life of the product. In addition to the safety instructions
in this operating manual, you must also observe the
regulations applicable to the operation of the product in
your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the product
on to third parties.
2 Product description (Fig. 1-21)
1. Stop
2. Grinding belt tensioner
3. Grinding belt 2x P80, 1x P120, 1x P240
(1x P80 pre-assembled)
4. Knurled screw for grinding belt adjustment
5. Grinding wheel
5a. Sanding disc 2x P80, 1x P120, 1x P240 sand-
paper (1x P80 pre-assembled)
5b. Quick-fit fastening system
5c. Fastening screw (grinding wheel)
5d. Rear wall (grinding wheel)
5e. Fastening screw (rear wall)
5f. Sanding disc holder
6. On/off switch
7. Transverse stop
8. Sanding table
8a. Philips screws
9. Locking screw for sanding table
10. Base plate
11. Mounting hole
12. Allen screw
13. Suction nozzle (grinding belt)
13a. Philips screw (suction nozzle grinding belt)
13b. Suction nozzle (grinding wheel)
14. Allen screw
14a. Washer
15. Screws (M8)*
16. Nuts (M8)*
17. Protective guard
18. Screws for disc guard
19. Wing screw
19a. Washer
20. Allen key
21. Grinding belt guard
22. Screws for grinding belt guard
23. Grinding belt holder
24. Deflection roller
25. Belt cover
25a. Clamping screw (belt cover)
26. Fixing screw
27. Belt
28. Adjusting screw belt tension
* = may not be included in the scope of delivery!
3 Scope of delivery (Fig. 2)
Item Quantity Designation
1. 1 x Stop
3. 3 x Grinding belt 2x P80, 1x P120,
1x P240 (1x P80 pre-assembled)
5a. 3 x Sanding disc 2x P80, 1x P120,
1x P240 sandpaper
(1x P80 pre-assembled)
7. 1 x Transverse stop
8. 1 x Sanding table
9. 1 x Locking screw for sanding table
14. 2 x Allen screw
14a. 2 x Washer
20. 1 x Allen key
1 x Belt and disc sander
1 x Operating manual
4 Proper use
The purpose of the belt and disc sander is to sand all
types of wood, depending on the size of the machine.
The machine complies with the applicable EC machin-
ery directive.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual.
GB | 23www.practixx.com
