22
|
GB
10. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions. The custom-
er‘s mains connection as well as the extension cable
used must also comply with these regulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables of the same designation.
The printing of the type designation on the connection
cable is mandatory.
For single-phase AC motors, we recommend a fuse
rating of C 16A or K 16A for machines with a high start-
ing current (from 3000 watts)!
11. Cleaning
m Attention!
Disconnect the mains plug before carrying out any
cleaning work.
We recommend that you clean the device directly after
every use.
Wipe swarf and dust o the machine from time to time
with a cloth.
8. Assembly / Before commissioning
m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
8.1 Machine stand assembly (g. 3 - 6)
• Secure the two wheels using a washer (15) and a
split pin (16) each (g. 3).
• Secure the right-hand side panel (5a) and the left-
hand side panel (5b) using two llister head screws
(18) and two hexagon nuts (19) (g. 4).
• Now t the intermediate part (13) using a total of four
llister head screws (17) (g. 5).
• Place the housing cpl. with engine (3) on the ma-
chine stand and x it with a total of eight llister head
screws (17) (g. 6).
8.2 Fitting the dust bag (g. 7)
• Attach the dust bag (10) to the lower air outlet using
the clamp tting (11) (g. 7).
8.3 Fitting the lter bag (g. 8)
• Insert the retaining rod (1) into the housing cpl. with
engine (3) and hook in the lter bag (2) (g. 7).
8.4 Fitting the suction hose (g. 9 + 10)
• Attach the suction hose (6) to the nozzle on the
housing cpl. with engine (3) and x it with a hose
clamp (14) (g. 9).
• Attach the hose coupling (8) to the other end of the
hose (6) using a hose clamp (14) (g. 10).
9. Start up
m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
9.1 Switching on/o, g. 1
• To switch on, set the ON/OFF switch (4) to position
“I”.
• To switch the device o again, set the ON/OFF
switch (4) to position “0”.
