~ 15 ~

4 DC Breaker

This breaker controls the power supply for the

battery pack.

Left: OFF

Right: ON

5 Protective earthing port

To protect people from electric shocks in the

event of a fault

6 Battery power ports

“+” is battery power positive port.

“-” is battery power negative port.

Table 2 Control box side description

Figure 7 Control Box Bottom Panel

No Item Description

7 Bottom Connector

Control box bottom connector that connects to

module top connector.

Table 3 Control box connector description
