10 OM-POWER PREP ADVANCED
Wash, rinse, and sanitize the walls of the sink and opening in the back wall with
the drain valve open. Remove all the food debris from the wash sink.
PUMP PURGE SYSTEM
After rinsing the debris from the wash sink, the pump housing will need to be
purged of debris. The purge valve will be used to ush clean rinse water through
the pump housing. Each position of the purge valve will ow fresh water to
spray in a specic area of the pump housing. The water will ow from the pump
housing into the wash sink carrying the debris that was left in the pump from the
wash operation. Examination of the ush water to see that it is free of debris will
determine when the pump housing has been properly ushed.
Pump Purge Procedure
1. Drain the water from the sink.
2. Remove all components from the wash sink including the jet channel, and the
intake screen. Wash and rinse each component thoroughly. Separate each
piece for drying.
3. Rinse the upper part of the sink walls and the discharge manifold and spray
water through the discharge manifold opening and into the pump.
4. Spray water into the intake opening, and rinse out the remainder of the sink.
Flow all debris toward the drain.
5. Remove all debris from the sink bottom and drain.
6. Operate the purge system stopping at each port (Positions 1, 2, and 3) for 5
seconds each. Rotate the handle of the purge valve clockwise, stopping at
each of the numbered locations.
7. Remove the dislodged debris from the discharge manifold and the sink
bottom.
8. Insert the jet channel and then ll the sink with water.
9. Run the pump for 60 seconds while performing the purge system sequence
described in Step 6.
10. Drain the water from the sink and inspect for cleanliness.
Purge valve
shown in the
“OFF” position
PREVENTATIVE MAINTENANCE
TURN OFF THE POWER TO THE POWER PREP ADVANCED AT THE MAIN
BREAKER PRIOR TO WORKING ON THE POWER PREP ADVANCED PUMP
OR MOTOR. FAILURE TO TAKE THIS STEP COULD RESULT IN ELECTRICAL
SHOCK THAT COULD RESULT IN SERIOUS INJURY OR DEATH.
The Power Prep Advanced system requires minimal routine preventive
maintenance. The following tasks should be completed on a routine basis to
ensure that the system remains reliable.
MONTHLY MAINTENANCE
Clean the pump motor fan shroud with a damp, soapy rag. The motor shroud is the
“vented” cover located at the end of the motor (closest to the control panel). This
cleaning will prevent grease and dust from accumulating in the cover’s openings
which can obstruct the airow that cools the motor.
DRAIN VALVE
The drain valve handle rotates ¼ turn to open or close the drain valve. Counterclockwise
rotation will open the drain valve; clockwise rotation will close the valve.
When the drain valve handle is horizontal, the valve is closed. When the drain valve
handle is vertical, the valve is open.
CLEANING
DO NOT ATTEMPT TO CLEAN THE POWER PREP ADVANCED WITH A
WATER JET. DOING SO COULD DAMAGE SEALS NOT DESIGNED FOR HIGH
PRESSURE AND COULD RESULT IN SERIOUS INJURY OR DEATH FROM
ELECTRICAL SHOCK.
DO NOT RUN THE WASH PUMP MOTOR WHEN THE WASH SINK IS EMPTY
AND THE PURGE SYSTEM IS TURNED OFF. OPERATING THE WASH PUMP
MOTOR WITHOUT WATER IN THE PUMP HOUSING WILL DAMAGE THE WASH
PUMP SEALS.
After the last batch of food has been washed, the Power Prep Advanced needs to
be disassembled and thoroughly cleaned. A recommended cleaning procedure
is included in this section. This procedure was determined for general operation.
Each owner of the Power Prep Advanced may have specic needs that have been
outlined in their own procedure that will supersede these instructions.
PARTS REMOVAL
Remove each Power Prep Advanced component in the reverse order it was
assembled. Wash each component to remove all traces of food debris. Position
each component so that it dries quickly. Pay particular attention to the ow guides;
provide airow between each of them for drying and do not stack them together
wet. Remove for cleaning:
• Wave guide
• Flow guides
• Divider board
• Rib sets
• Intake screen
• Jet channel
