11 OM-POWER PREP ADVANCED

Inspect the entire system for total cleanliness including the manifolds.

De-lime the wash sink by adding a de-liming agent to a full sink of warm, fresh

water and run the wash pump overnight. Ask a chemical sales representative to

recommend a specic de-liming agent known to be effective in your area.

For questions regarding the preventive maintenance procedures, please contact

the Power Soak service department at 888-994-7636.

TROUBLESHOOTING

ONLY A LIMITED NUMBER OF TROUBLESHOOTING AND REPAIR

PROCEDURES MAY BE PERFORMED BY THE FACILITY OWNER OR

MANAGER. ANY TROUBLESHOOTING OR REPAIR THAT REQUIRES THE

REMOVAL OF FASTENERS OR THAT ENTAILS ELECTRICAL SERVICE MUST

NOT BE ATTEMPTED BY ANYONE OTHER THAN AN AUTHORIZED SERVICE

AGENCY. TO OBTAIN THE NAME OF A RECOMMENDED SERVICE AGENT IN

YOUR AREA, PLEASE CALL THE POWER SOAK SERVICE DEPARTMENT AT

AT 888-994-7636.

SYMPTOM POSSIBLE CAUSE REMEDY

Pump motor will

not run

Circuit breaker

accidentally turned off

Turn breaker on.

Circuit breaker tripped Investigate reason for tripping, e.g.

damaged wiring, undersized breaker.

Contact Power Soak service or an

authorized service agency.

Motor thermal overload

tripped

Investigate reason for overload tripping,

e.g. debris stuck in pump impeller. If

debris removal requires that you remove

any fasteners, contact Power Soak

service or an authorized service agency.

Once rectied, reset thermal overload

by pressing button on bottom of motor

junction box.

Start capacitor

defective (single

phase motors only)

Replace capacitor. To do this, contact

Power Soak service or an authorized

service agency.

Unit too warm Pump clogged with

food

Ensure door / drawer is fully closed.

Motor is running on

the wrong voltage

(initial installation)

Lock and tag out the electrical power from

the unit. Remove the three adapter plate

retaining nuts adjacent to the motor. Slide

the motor, adapter plate, and impeller out

of the pump housing. Remove debris from

the impeller and reassemble. Contact

Power Soak service or an authorized

service agency for this service.

Motor is running the

wrong direction (initial

installation)

For three phase motors, reverse any two

motor leads. For single phase motors,

reconnect motor internal leads according

to the motor nameplate instructions.

Contact Power Soak service or an

authorized service agency to safely change

the rotation.

Unit makes a

loud, steady

noise when

running

Debris caught in the

motor’s cooling fan

Lock and tag out the electrical power

from the unit, remove the motor fan cover,

and remove the debris. Replace the fan

cover and restore the power. For this

task, Contact Power Soak service or an

authorized service agency.

Motor seal running dry Lock and tag out the electrical power

from the unit, remove the motor fan cover,

and squirt some low viscosity oil such as

WD40 between the fan and the motor end

bell. Replace the fan cover and restore the

power. Contact Power Soak service or an

authorized service agency for service of

this nature.

Debris caught in the

pump impeller

Lock and tag out the electrical power

from the unit. Remove the three adapter

plate retaining screws adjacent to the

motor. Slide the motor, adapter plate, and

impeller out of the pump housing. Remove

debris from the impeller and reassemble.

Contact Power Soak service or an

authorized service agency for this service.
