Color Temp/Color Space/Gamma Menu
Camera Assist Menu
Zebra & False Color
- Evaluates the Luma(Y’) level of the input image.
If the certain Y’ level is set, the pixels with the
designated Luma(Y’) level are displayed in
zebra paern.
Zebra
Pixels with Y’ level over 100% turn to red
zebra paern, and pixels with Y’ level under
0% turn to green zebra paern.
Zebra Level Adjustment
- Adjusts the Y’ level as the user wants.
Zebra Range
- Adjusts the Y’ level as the user wants.
False Color ARRI
The color paern is displayed with ARRI camera
standard.
False Color Variable
This mode allows the user to adjust White
clipping, Pink level, Green level, Black Clipping.
Variable White Clipping
- Adjusts White Clipping from 0 to 1023.
Variable Pink Level
- Adjusts Pink level from 0 to 1023.
Variable Green Level
- Adjusts Green level from 0 to 1023.
Variable Black Clipping
- Adjusts Black Clipping from 0 to 1023.
Page 1/2
Color
red
yellow
pink
green
blue
purple
Level
99~100%
97~99%
52~56%
38~42%
2.5~4.0%
0~2.5%
Descripon
White clipping
Just below white clipping/white shoulder
One stop over medium gray (Caucassian skin)
18% neutral gray
Just above black clipping/black slope
Black clipping
*Back Light
Adjusts the level of the back light level.
If the back light value is increased, the screen
becomes brighter.
** If the seng in Color Temp. menu and Color
Space menu is changed, the value of Back Light
returns to the default value of the color calibraon
in the factory.
Page 3/3
*RGB/YCC Range
- Selects Black Level and White Level of RGB/YCC
format.
SDI : -Limited : 64(10bit)/256(12bit)~
1023(10bit)/4095(12bit)
-Full : 4/16(Black Level) ~
1023(10bit)/4095(12bit)
HDMI : - Limited : 64(10bit)/256(12bit)~
1023(10bit)/4095(12bit)
-Full : 0(Black Level) ~
1023(10bit)/4095(12bit)
*HDR Auto Seng
This funcon allows the monitor to read the
Transfer Characteriscs and Colorimetry informaon
of Payload idenfiers of the ST 2082-10 12G SDI
signal and adjust HDR automacally.
- Transfer Characteriscs : SDR, ST2084-1000, HLG1.2
- Colorimetry : Rec709, Rec 2020
PRM- 12G Series
12G-SDI Professional
17
12G Multi-Channel Rack Monitors
