Color Temp/Color Space/Gamma Menu
** 1) OSD Menu of this mode is different,
depending on each model’s HDR maximum
luminance.
HDR maximum luminance
OBM-U17IP : 1000 cd/m²
OBM-U24IP : 400 cd/m²
OBM-U31IP : 700 cd/m²
OBM-U42IP : 400 cd/m²
2) PQ and HLG gamma is different, depending on
each model’s luminance.
OBM-U17IP : ST 2084-1000 - HLG-1.2(1000)
OBM-U24IP : ST 2084-400 - HLG-1.03(400)
OBM-U31IP : ST 2084-700 - HLG-1.13(700)
OBM-U42IP : ST 2084-400 - HLG-1.03(400)
Gamma
Selects the appropriate gamma mode from 1.00
to 3.00.
**Note - When the HDR-EOTF is set [SDR], this
menu becomes acvated. - When the color
space is set to [Nave] or [ACES Proxy], this
menu becomes deacvated.
When the color space is set to Nave, this
menu becomes deacvated.
Back Light
Adjusts the level of the back light level.
If the back light value is increased, the screen
becomes brighter.
** If the seng in Color Temp. menu and Color
Space menu is changed, the value of Back
Light returns to the default value of the color
calibraon in the factory.
Camera Log
Selects a camera log for the input signal.
[Off]: Sets off the camera log.
[Default]: The log which is selected in [Default
Log Sel.] menu is applied.
[User]: The log which is selected in [User Log
Sel.] menu is applied.
[Import Log Data]: Allows the user to save the
Log LUT in USB memory sck
to the monitor. The saved
LUT can be used in User Log.
Default Log Sel
Allows the user to select a camera log among
Log-C EI 160~3200, S-Log2 To LC-709,
S-Log2 To LC-709TypeA, S-Log2 To Slog2-709,
S-Log2 To Cine+709, S-Log2 To LC-709, S-Log3
To LC-709TypeA, S-Log3 To Slog2-709, S-Log3
To Cine+709, J-Log1.
User Log Sel
Selects User Log 1 to 4.
**Note
- If you insert the USB memory sck which contains
the user log data to the monitor and push Enter in
[Import Log Data] menu, the data is saved to the
monitor.
- The file name of the user log data is displayed on
the OSD up to 15 characters, and the log data file
should be placed on the top folder of the USB
memory sck.
Ex) If the file name is ‘S-log3 to LC709_A.cube’,
it is displayed as ‘S-log3 to LC709’ on the
OSD.
OBM-4K-IP Series
4K-IP LCD Professional Monitor
12G-SDI / SFP-IP
18
