MAINTENANCE
Warning
The mains power plug must be removed from the mains power socket
before any maintenance or replacement.
If the mains power cable is damaged, it must be replaced by the
manufacturer or its service agent or an appropriately qualified person in
order to avoid a hazard.
10
1. Changing the dust bag: when the dust full indicator turns red or loss
of suction is noticed, it is time to clear the dust bag or replace it with a
new bag. (Fig 10)
Open the front cover by touching front cover button. (Fig 11)
Take out the bag holder then remove the full dust bag. (Fig 12)
Installing the dust bag: insert the dust bag into the bag holder and then
put it in the slot cabinet. (Fig 13)
2. Cleaning the inlet filter: clean the filter with warm water and allow to
dry fully before placing back into the vacuum cleaner. (Fig 14)
Replacing the inlet filter: clip down and remove the inlet cover, remove
and replace with a suitable filter. (Fig 15)
3. Cleaning the outlet filter: open the outlet cover and take out the HEPA
frame and filter. Wash it and install it after the filter has fully dried.
(Fig 16/17)
Fig 10 Fig 11 Fig 12 Fig 13
Fig 14 Fig 15 Fig 16 Fig 17
