ATTACHMENTS
GB
1
2
4
5
3
9
ASSEMBLY BEFORE USE
Fig.1 shows the connection of the hose to the vacuum cleaner:
Put the hose connector in front of the vacuum cleaner.Then insert it into
the inlet hole. If you want to disassemble it, you can press the release
button and then pull it out.
Fig.2 shows the connection of the hose to the extending metal tube:
Hold the flexural connector of the hose to put it into the bigger hole of
the tube.
Fig.3 shows the connection of the tube to the brush tool:
Put the metal tube into the hole of the brush and rotate it to fasten
them.
Fig.4 shows how to pull out and retract the power cable.
You can pull the power cable out of the vacuum cleaner and stop it when
you see the yellow mark. Make sure the red mark is not out. When you
have finished vacuuming, first turn o the power, then pull the plug out
of the socket, then push the winding device button until the cable is
completely in the vacuum cleaner.
Fig.5 shows the power button
Put the plug into the socket, push the power button to turn on the
vacuum cleaner.
